Hydraulic Folding Machine
YCB Series
Capacity: 1.6 mm
Width: 1230-2440 mm
Min Angle: 60°
SPECIFICATION
YCB SERIES
Under our continuous R&D, for any change in specifications without prior notice.
*A:Mild steel
*B:Stainless steel
| T L S | 1mm | 1.2mm | 1.6mm | 1.8mm | 2mm | |
| 5mm | 6mm | 8mm | 9mm | 10mm | ||
| YCB-1230 | A | 1230 | 1230 | 1000 | 800 | 600 |
| B | 1000 | 800 | 700 | 600 | 400 | |
| YCB-1830 | A | 1830 | 1500 | 1200 | 1000 | 800 |
| B | 1600 | 1200 | 1000 | 800 | 600 | |
| YCB-2030 | A | 2030 | 1600 | 1400 | 1200 | 1000 |
| B | 1800 | 1400 | 1200 | 1000 | 800 | |
| YCB-2440 | A | 2440 | 2200 | 2200 | 1800 | 1600 |
| B | 2200 | 2000 | 1800 | 1600 | 1400 |
PRESSURE KNIFE
| TYPE | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 |
| LENGTH | 45 | 75 | 95 | 115 | 135 | 165 | 175 | 200 | 235 | 250 | 295 | 315 | 345 |
| Model |
Folding |
Folding | Weight (Kgs) | Minimum Folding | Folding Angle | Packing Size(mm) (L) (W) (H) | ||
| YCB-1230 | 1230 | 1.6 | 550 | 60° | Any Angle | 2080 | 850 | 1250 |
| YCB-1830 | 1830 | 1.6 | 900 | 60° | Any Angle | 2700 | 850 | 1250 |
| YCB-2030 | 2030 | 1.6 | 1000 | 60° | Any Angle | 2850 | 850 | 1250 |
| YCB-2440 | 2440 | 1.6 | 1250 | 60° | Any Angle | 3300 | 850 | 1250 |
